Removal and Installation

NOTE:
- Repair is made by replacement only. If a part is replaced and the new part does not correct the condition, install the original part and perform the diagnostic procedure again.




1. Disconnect the negative battery cable and wait at least one minute.
2. Open the glove compartment door to access the mounting screws.
3. Remove the two screws (1).

CAUTION:
- Do not handle the passenger-side air bag module by grabbing the edges of the deployment doors.

4. Placing one hand in the glove compartment, push the passenger-side air bag module out enough to access the electrical connector.
5. Disconnect the electrical connector (2).
6. Remove passenger-side air bag module (3).
7. Install in reverse order of removal.
