Door Glass Run

Door Glass Run

Removal

1. Remove door trim panel and watershield. Doors

2. Remove inner belt weatherstrip.

3. Remove door glass.

4. Remove run retaining bolt.

5. Remove door glass run from door.

Installation

1. Install run assembly into door frame.

2. Push run onto door flange starting at upper B-pillar corner.

3. Continue down B-pillar and then across top of door frame and down A-pillar.

4. Install glass run retaining screw and washer assembly.

5. Install door glass run retainer with upper bracket locked into door.

6. Install door glass.

7. Install inner belt weatherstrip.

8. Adjust door glass.

9. Install watershield and door trim panel. Doors
