Brake Caliper Anchor Plate

Removal and Installation
1. Remove the brake pads.





2. Remove the brake caliper anchor plate.
1 Remove the brake caliper anchor plate bolts.
2 Remove the brake caliper anchor plate.
3. To install, reverse the removal procedure.
