Timing Belt Tensioner

CHAIN TENSIONER ASSEMBLY NO.1





Temporarily install the tensioner with the 2 bolts. Alternately tighten the 2 bolts.
Torque 27 Nm (280 kgf-cm, 20 ft-lbf)

NOTE: Be sure to tighten the bolts equally. Installing the tensioner at an angle may cause improper operation.
