Installation

HEATING / AIR CONDITIONING: REAR BLOWER MOTOR: INSTALLATION





1. INSTALL BLOWER WITH FAN (REAR) MOTOR SUB-ASSEMBLY
(a) Install the motor with the 3 screws.
(b) Connect the connector.
2. INSTALL REAR COOLING UNIT ASSEMBLY
(a) Install the rear cooling unit assembly Installation.
