Windshield Washer Pump: Service and Repair

REMOVE

Washer Reservoir:

1. Disconnect the washer tubing from the pump.
2. Disconnect the electrical leads from the pump
3. Pull the top of the pump away from its location in the reservoir and remove the pump. Note the position of the sealing gasket in the reservoir.

REFIT
1. Reverse instructions 1 to 3.
