Verifying Bearing Preload (Differential)

Measure the preload as follows:





1. Set the differential assembly into the clutch housing.





2. Install the transaxle case onto the clutch housing.





3. Install the SST to the differential side gear through the transaxle case.





4. Measure the bearing preload.

Preload: 13.59-22.64 inch lbs. (1.53-2.55 Nm)

5. If not as specified, readjust the bearing preload.
6. Remove the SST.
7. Remove the transaxle case and differential assembly.
