Front Seat Back Frame

SEAT BACK FRAME REPLACEMENT
1. Remove the following items.
- Recliner cover.
- Seat back panel.
- Headrest guide.
- Seat backcover.




2. Remove the pad (A) from frame (B).

CAUTION:
- Remove the side airbag for replacing side air bag installation seat.
- Be fore service, be fully aware of precautions and service procedure relevant to air bag.

3. Installation is the reverse of removal.
