Safing Sensor

Test 1:

SYMPTOM
SAFING SENSOR

TEST NOTE
This symptom is diagnosed using the test ACCELEROMETER 1.

WHEN MONITORED
With the ignition on, the module on board diagnostics continuously performs internal circuit tests.

SET CONDITION
This DTC will set if the module identifies an out of range internal sensor.

POSSIBLE CAUSES
- Airbag control module - ACM
