Lock-Up Module Replacement

Fig. 15 Lock-up Module Disassembly:

1. Remove end cover, Fig. 15.
2. Remove lock-up spring and valve.
3. Remove fail-safe valve and spring.
4. Tag these springs as they are removed for reassembly.
