Diagnostic Procedure 4

Diagnostic Procedure 4:




^ Perform "IVMS Communication Diagnosis" and "Power Supply and Ground Circuit Check" as necessary before starting Diagnostic Procedures.
Symptom: Light warning buzzer does not activate.
