Speedometer Head: Testing and Inspection

Speed Sensor Signal Check






1. Remove speed sensor from transmission.
2. Turn speedometer pinion quickly and measure voltage across (a) and (b)

Note: No procedures are given by Manufacturer for speedo head. If Speed Sensor is OK, check connections, power source and grounds to instument cluster. Unit is serviced as an assembly.
