System Inspection

System Inspection

Alternator circuit inspection
1. Engine "ON"
2. Turn on the head rights and heat rays at idle status, and accelerate to 2500 RPM for 2 min.
3. Check voltage between battery + terminal and - terminal.

measurement value : about 12.5 - 14.7V





4. Is the measured waveform within specifications ?
