Seat Assembly Replacement

Replacement

Seat Assembly Replacement
1. Remove the rear seat cushion (A).
2. Disconnect the connector (B).




3. Loosen the mounting bolt, then remove the side seat back (A).




4. Remove the rear seat back (A).




5. Installation is the reverse of removal.
