Rear Bumper Reinforcement: Service and Repair

REAR BUMPER RAIL REPLACEMENT

1. Remove the front bumper cover.
2. Remove the clips.
3. Remove the rear bumper rail (A).
4. Installation is the reverse of removal.

NOTE: Replace any damage clips.
