Fuel Pump: Service and Repair

This article has been updated by techincal service bulletin TSB 06-30-001 dated JANUARY, 2006.

The 2003-2005 Accent Shop Manuals contain incorrect information for the fuel filter location.

REPLACEMENT

FUEL FILTER AND PUMP REPLACEMENT
1. Reduce the internal pressure of the fuel lines and hoses by completing the following operations.

- After removing the rear seat cushion, disconnect the fuel pump harness.
- Start the engine. Allow it to stop by itself, then turn the ignition switch OFF.
- Disconnect the battery negative (-) terminal.




- Connect the fuel pump harness connector.

2. Remove the eye bolts while holding the fuel filter nuts securely.

CAUTION: Cover the fuel filter with a shop towel to avoid residual gasoline from splashing.






For the 2003-2005MY the fuel filter is incorporated into the fuel pump assembly within the fuel tank.
- Part Number: 31112-25700 (Filter-Fuel Injection Pump).

3. Remove the fuel filter mounting bolts, then remove the fuel filter from the fuel filter clamp.

4. After replacing the fuel filter, check for fuel leaks.
