Component Inspection

Body Control Module

B1906 Rain sensor fault2 - Component Inspection

Component Inspection

1. Check rain sensor
(1) Check attached condition between windshield and rain sensor.




(2) Is attached condition normal?
YES
1) Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage.
Repair or replace as necessary and then go to "Verification of Vehicle Repair" procedure.
NO
1) Replace rain sensor and Go to "Verification of Vehicle Repair" procedure.
