Oil Spray Jet: Service and Repair

Oil Jet Replacement

1. Remove the oil pump.
2. Remove the baffle plate.
3. Remove the oil jet bolts (A), then remove the oil jets (B).





4. Carefully install the oil jets, and tighten the oil jet bolts.
5. Install the baffle plate.
6. Install the oil pump.
