Rear Door Latch - Lower, LH

Rear Door Latch - Lower, LH










1. Remove the left rear door trim panel.

2. Remove the 2 left rear door lower latch bolts.
- To install, tighten to 12 Nm (106 lb-in).


3. Open the clip and disconnect the left rear door upper latch cable from the remote control.

4. Remove the left rear door handle screw and handle.

5. Remove the 2 left rear door remote control bolts.
- To install, tighten to 12 Nm (106 lb-in).


6. Remove the left rear door lower latch from the door.

7. To install, reverse the removal procedure.
