Pressure Cutoff Switch

REMOVAL







1. Disconnect the A/C pressure cutoff switch electrical connector.







2. Remove the A/C pressure cutoff switch.
^ Discard the O-ring seal.

INSTALLATION
1. To install, reverse the removal procedure.
^ Install a new O-ring seal lubricated in clean PAG oil.
