Pump Shaft

1. Note: Inspect the pump drive shaft in the area that the bearings ride. If worn, install a new shaft and main control.

Remove the Teflon(R) seals and inspect the shaft.





2. Note: Make sure that the seals are installed correctly.

Install four new seals on the pump shaft.
