AECM Output Driver Circuit Open (Active)

Test 1:

SYMPTOM
AECM OUTPUT DRIVER CIRCUIT OPEN (ACTIVE)

TEST NOTE
This symptom is diagnosed using the test ACM ACCELEROMETER (ACTIVE).

WHEN MONITORED
Continuously with ignition ON.

SET CONDITION
The ACM has detected a diagnostic condition , replace the module.

POSSIBLE CAUSES
- ACM, Active/Stored code
