A. Clean Carburetor

1. Remove air cleaner assembly.

2. Clean the outside of the carburetor and the choke linkage with MOPAR Brake and Carburetor Parts Cleaner or equivalent.





3. Clean the Primary Air Bleed Jet, Secondary Air Bleed Jet, and Choke Shaft (Figure 1).
