Radio Front Speaker Replacement



Radio Front Speaker Replacement

Removal Procedure

1. Remove the front door trim panel.
2. Disconnect the electrical connector.




3. Unsnap the speaker from the lock module.

Installation Procedure




1. Snap the speaker into the lock module.
2. Connect the electrical connector.
3. Install the front door trim panel.
