Door Sill Plate Replacement - Lift Gate

DOOR SILL PLATE REPLACEMENT - LIFT GATE

TOOLS REQUIRED
J 38778 Door Trim Pad and Garnish Clip Remover

REMOVAL PROCEDURE




Use the J 38778 in order to remove the door sill trim plate from the vehicle.

INSTALLATION PROCEDURE




Install the door sill trim plate to the vehicle. Align the retainers along the door sill and press into place.
