Heat Shield Replacement

Remove or Disconnect
1. Raise vehicle and suitably support.
2. Bolts/screws from heat shield.
3. Heat shield.


Install or Connect
1. Heat shield.
2. Bolts/screws to heat shield.
^ Tighten bolt/screw to 6 Nm (54 inch lbs.).
3. Lower vehicle.
