C1282

CIRCUIT DESCRIPTION
DTC C1282 allows the EBCM/EBTCM to inspect for a calibration malfunction by comparing the calibration value to a known value (checksum). The EEPROM stores the checksum.
DTC C1282 also acts as a security measure to prevent improper use of calibrations or changes to these calibrations. Improper calibrations may alter the designed function of ABS/TCS

CONDITIONS FOR SETTING THE DTC
DTC C1282 can set any time after the ignition is turned to the Run position.
A malfunction exists if the program identifier is incorrect or the memory checksum is incorrect.

ACTION TAKEN WHEN THE DTC SETS
- A malfunction Diagnostic Trouble Code (DTC) stores.
- The ABS/TCS disables.
- The amber ABS/TCS warning indicator(s) turn on.

CONDITIONS FOR CLEARING THE DTC
- The condition responsible for setting the DTC no longer exists and the Scan Tool Clear DTC function is used.
- 100 drive cycles pass with no DTC detected.

DIAGNOSTIC AIDS
A bad cell in the EEPROM that is sensitive to temperature changes may cause an intermittent DTC C1282. If DTC C1282 sets more than once but is intermittent replace EBCM/EBTCM.
Use the enhanced diagnostic function of the Scan Tool in order to measure the frequency of the malfunction. Refer to the Scan Tool manual for the procedure.
