CHMSL Bulb Replacement

Description:

Remove or Disconnect
1. Screws that retain the CHMSL lens to the vehicle.
2. CHMSL lens from the vehicle.
3. CHMSL bulb(s).

Install or Connect
1. CHMSL bulb(s).
2. CHMSL lens to the vehicle.
- Make sure that the CHMSL lens gasket is properly seated.
3. Screws that retain the CHMSL lens to the vehicle.

Tighten
- CHMSL lens screws to 2.5 N.m (22 lb in).
