Heater System

Blower Motor Resistor Without A/C:

REMOVE OR DISCONNECT


1. Negative battery cable.

2. Electrical connector.

3. Blower motor resistor screws.

4. Blower motor resistor.

INSTALL OR CONNECT

1. Blower motor resistor.

NOTICE: Refer to "Fasteners" under "Vehicle Damage Warnings."


2. Blower motor resistor screws.

- Tighten screws to 1.9 Nm (17 lbs. in.).


3. Electrical connector.

4. Negative battery cable.

- Perform "Heater Function Test."
