Rear

Rear Heater Component View:

REMOVE OR DISCONNECT
1. Negative battery cable.
2. Body side front lower trim panel.
3. Two electrical connectors.
^ Note connector locations.
4. Five retaining screws.
5. Blower motor and fan from the case.
^ Note blower and fan assembly orientation.

INSTALL OR CONNECT
1. Blower motor and fan to the blower case.
2. Five retaining screws.
3. Electrical connectors.
4. Body side front lower trim panel.
5. Negative battery cable.
