Home >> Chevrolet >> 2005 >> Malibu V6-3.5L VIN 8 >> Repair and Diagnosis >> Transmission and Drivetrain >> Automatic Transmission/Transaxle >> Fluid - A/T >> Testing and Inspection >> Transmission Fluid Checking Procedure

Transmission Fluid Checking Procedure



Transmission Fluid Checking Procedure

Transmission Fluid Check:


















The oil level control plug (65) is located on the torque converter side of the transmission.
