Console Trim Plate Replacement - Console Rear (With RPO Code U32)

TRIM PLATE REPLACEMENT - CONSOLE REAR (With RPO Code U32)

REMOVAL PROCEDURE
1. Remove the console armrest.




2. Remove the hinge trim cover.
3. Remove the video display.




4. Remove the upper trim plate.




5. Remove the lower trim plate.

INSTALLATION PROCEDURE




1. Install the lower trim plate.




2. Install the upper trim plate.
3. Install the video display.




4. Install the hinge trim cover.
5. Install the console armrest.
