P1630

CIRCUIT DESCRIPTION

This diagnostic test checks for the Enable Password Learning Flag indicating the PCM is in learn password mode. This mode allows the PCM to learn the password from the Body Control Module (BCM) at assembly or when serviced. The password needs to be learned whenever the PCM or the BCM is replaced or an ignition key that has an improper resistance.

CONDITIONS FOR SETTING THE DTC

The PCM is ready to learn a new password from the BCM, but the BCM is not sending a valid password or not sending a password at all.

ACTION TAKEN WHEN THE DTC SETS

^ The engine starts and stalls when the BCM detects a theft mode.

^ The engine starts and stalls when the PCM losses communication with the BCM.

^ The engine operates normally, but an internal BCM failure has occurred.

^ The PCM stores the DTC information into memory when the diagnostic runs and fails.

^ The Malfunction Indicator Lamp (MIL) will not illuminate.

^ The PCM records the operating conditions at the time the diagnostic fails. The PCM stores this information in the Failure Records.

CONDITIONS FOR CLEARING THE MIL/DTC

^ A History DTC will clear after forty consecutive warm-up cycles, if no failures are reported by this or any other non-emission related diagnostic.

^ A last test failed (Current DTC) will clear when the diagnostic runs and does not fail.

^ The PCM battery voltage is interrupted.

^ Use a scan tool in order to clear the MIL/DTC.


DIAGNOSTIC AIDS

The PCM in learn mode is a DTC for the vehicle at the assembly plant, dealership, and the outside garage personnel as an indication that the system enables the learn mode. This means the PCM is now ready to learn a new password from the BCM. This DTC set because the BCM never sent a valid password to the PCM while in learn mode. When this occurs, the vehicle is vulnerable to vehicle theft.
