Chassis/Canister

REMOVAL PROCEDURE
1. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle.




2. Disconnect the EVAP purge pipe at the fuel filter area.
3. Disconnect the EVAP hose (7) from the canister (1).




4. Disconnect the EVAP purge pipe (8) from the EVAP canister (1).
5. Remove the EVAP purge pipe (8).

INSTALLATION PROCEDURE




1. Connect the EVAP purge pipe (8) to the EVAP canister (1).
2. Connect the EVAP canister hose (7) to the canister (1).




3. Connect the EVAP purge pipe to the fuel filter area.
4. Lower the vehicle.
