Left Mount

REMOVE OR DISCONNECT
1. Raise vehicle.
2. Support transaxle with jackstand(s).
3. Bolt from frame to mount.
4. Bolts from mount to transaxle.
5. Mount.

INSTALL OR CONNECT
1. Mount into position.
2. Bolts, mount to transaxle.
3. Bolt, frame to mount.

Tighten
- Mount to transaxle bolts to 58 N.m (43 lb. ft.).
- Frame to mount bolt to 85 N.m (63 lb. ft.).

4. Remove jackstand.
5. Lower vehicle.
