Completion - Windshield/Backglass

Completion - Windshield

1. Install all reveal moldings.

2. Tape glass and moldings to hold position.

3. Install wiper down stops to cowl screen assembly.

4. Install windshield wipers and blades.

5. Vehicle must remain at normal room temperature for six hours to complete proper curing of adhesive.

6. After curing is complete, clean up tape and excess sealant.


Completion - Backglass

Install or Connect
1. Install all reveal moldings.

2. Tape glass and moldings to hold position.

3. Center high mount stop lamp.

4. Rear defogger connectors.

5. Upper quarter trim panels.

6. Seatback.

7. Seat cushion.

8. Decklid (Oldsmobile only).

9. Vehicle must remain at normal room temperature for six hours to properly cure the urethane adhesive.

10. After curing is complete, clean up tape and excess sealant.
