Parts Information and Service Procedure

PARTS INFORMATION

Labels required to complete this activity are being provided to owners of record and in the dealer mailing at no charge to the dealer. If additional labels are required, they may be obtained from TUAR by calling (313) 239-5552.

ITEM NUMBER DESCRIPTION QUANTITY/VEHICLE

0415910000 Fuse Identification Label 1

SERVICE PROCEDURE





1. Turn two screws on left side of Instrument Panel (I.P.) 1/4 turn counterclockwise and remove left I.P. accessory trim plate.

2. Install new fuse information label (Item # 0415910000) over existing label on back side of accessory trim plate.

3. Reinstall accessory trim plate.

4. Install Campaign Identification Label.
