Seat Belts - Child Seat Installation W/ Automatic Belts

89buick11

Bulletin: 890908

Date: July, 89


Ref. No.: 89-115-9

Corp. Ref. No.: 981601R

FIGURE 1:

FIGURE 2:

SUBJECT: CHILD SEAT INSTALLATION ON VEHICLES EQUIPPED WITH AUTOMATIC SAFETY BELTS

MODELS AFFECTED: 1987-89 MODELS WITH DOOR MOUNTED AUTOMATIC SAFETY BELT SYSTEMS


To install a child's seat in Skylarks, Regals, and LeSabres equipped with automatic safety belts, a separate child seat restraint is required. A child seat restraint belt package is available only as a dealer installed option. Belts are available only in the color black. Accessory packages listed below are available through GMSPO.

Years and Models Part No Description

1987-89 LeSabres 999564 Belt/Hardware Package

1987-89 Skylarks 12340286 Belt Only
12340234 Hardware Package

1988-89 Regals 12340286 Belt Only
12340243 Hardware Only

Parts are currently available from GMSPO.

Refer to figures 1 and 2 for copies of the installation instruction sheet and template that are in the Hardware packages.

The child seat restraint accessory belt package kit and installation of same will be on a "No Charge to Owner" basis.

WARRANTY INFORMATION

Labor Operation Number: C9170
Labor Time: .2 Hours
Trouble Code: 92
