Replacing Left Fresh-Air Grill

Removing And Installing/Replacing Left Fresh-Air Grill







For purposes of clarity:
Fresh air grill (1) in unlocked state







Move air outlet adjuster (1) into illustrated position
Insert special tool 64 1 020 as illustrated at an angle downwards into openings of fresh air grill (2) and unlock fresh air grill (2).
Withdraw fresh air grill (2) at air outlet adjusters (1) in direction of arrow

Installation:
First allow fresh air grill (2) to snap into place at top.
Fresh air grill (2) must snap audibly into place.
