Temperature Control Switch (1)

The frostier, footwell, and rear area heating can be increased by turning the temperature control switch in a clockwise direction. The pre-selected temperature will be reached shortly thereafter in accordance with engine coolant operating temperature.

The temperature control switch has a "temperature scale", which should be "used as a reference point for temperature setting. These values should he regarded as approximate temperature stints since there may be a difference in temperature between the front and rear as well as the upper and lower areas of the passenger compartment.

The selected temperature does not need to be manually readjusted for full heat distribution after a cold start since the temperature will be adjusted for full heat to the passenger until the pre-selected temperature is reached.

There is no automatic temperature control at the extreme temperature settings; there will be either maximum heating or maximum cooling. To prevent undesirable fluctuations in temperature setting only selective at first.
