Shift Boot: Service and Repair

Selector Lever Boot, Separating from Handle

Removing

- Remove selector lever handle => [ Selector Lever Handle ] Selector Lever Handle.

- Bind spring tabs - 1 - of selector lever handle together with a cable tie - 3 -, as shown in the illustration.





- Push sleeve - 2 - of selector lever boot over the retaining tabs on the spring tabs - arrow -.

- Remove cable tie and remove sleeve with selector lever boot from selector lever.

Installing

Install in reverse order, paying attention to the following:

Installation position of selector lever boot:

• The longer side of the frame for selector lever boot faces toward the driver side.

- Install selector lever handle => [ Selector Lever Handle ] Selector Lever Handle.
