Front

Wiper Blade Park Position, Setting

- Allow wiper motor to run into park position.







- Position wiper blades on windshield and align as follows:







NOTE: The figures given here are the distances between wiper blades and cowl panel grille of plenum chamber at bottom edge of windshield.

- Tighten nut for wiper arms to 21 Nm.
- Actuate flick wipe switch.
- If necessary, realign wiper arms and retighten nuts.
