Hands-Free Microphone, Assembly and Installing

The hands-free microphone is located behind the left A-pillar interior trim piece (arrow).





- Remove left A-pillar trim.





- Remove A-pillar clips from trim and transfer them to the new A-pillar trim -1- (arrow).
- 4A0 867 231 D 7ZU left A-pillar trim -1-: ecru (beige)
- 4A0 867 231 D 8ZU left A-pillar trim -1-: platinum (grey)
- Using two phillips head screws, part no. N 13968 1 in kit part no. 4A0 051 431A, install hands-free microphone -3-, part no. 4A0 862 373 to the new A-pillar trim.
- Connect microphone plug connector -4- to the microphone harness connector -5-.


NOTE: This harness may be folded and taped down onto A-pillar.


- Wrap insulating wrap -6-, part no. 447 857 991J in kit part no. 4A0 051 431A, around connector and microphone harness.
- Reinstall A-pillar trim.
