Home >> Audi >> 1986 >> Coupe GT L5-2226cc 2.22L SOHC (KX) >> Repair and Diagnosis >> Powertrain Management >> Computers and Control Systems >> Relays and Modules - Computers and Control Systems >> Engine Control Module >> Diagrams >> Diagram Information and Instructions >> Diagrams By Track Number >> Tracks 1 Thru 190 >> Track 114 Thru 125

Track 114 Thru 125

Horns. Wiring Diagram:
