Hazard Warning Switch: Service and Repair

Hazard Warning Switch Test/Replacement

1. Remove these items:

- Audio-navigation and HVAC switch panel (with navigation system) Audio-Navigation and HVAC Switch Panel Removal/Installation
- Audio and HVAC switch panel (without navigation system) Audio and HVAC Switch Panel Removal/Installation

2. Push out the hazard warning switch (A) from behind the vent panel.





3. Disconnect the 5P connector (B) from the hazard warning switch.

4. Check for continuity between the terminals in each switch position according to the table.





5. If the continuity is not as specified, replace the hazard warning switch.

6. Install the switch in the reverse order of removal.
