Crankshaft Main Bearing: Specifications

Crankshaft bearing Specifications

Crankshaft bearing





Main bearing cap





Torque 29 N-m (3.0 kgf-m, 22 lbf-ft)
Tighten additional 48 °





Torque the 8 mm bolts 22 N-m (2.2 kgf-m, 16 lbf-ft)

Main Journal Code Location
