USB Adapter Unit Replacement

USB Adapter Unit Replacement

1. Remove the center console. Center Console Removal/Installation

2. Disconnect connectors (A) from the AcuraLink control unit (XM receiver) (B).

3. Remove the mounting nuts (C) and the AcuraLink control unit (XM receiver).

4. Install the USB adapter unit in the reverse order of removal.
