Mainshaft Bearing Removal

Mainshaft Bearing Removal

Special Tools Required

- Driver 07749-0010000
- Attachment, 78 x 80 mm 07NAD-PX40100
1. To remove the mainshaft bearing, expand the snap ring with the snap ring pliers, then push the bearing out. Do not remove the snap ring unless it's necessary to clean the groove in the housing.
