Coooling Fan Motor Test

COOLING FAN MOTORS / TEST
1. Disconnect the 2-P connector from the fan motor.
2. Test the motor by connecting battery power to the B terminal, and ground to the A terminal.







3. If the fan motor fails to run smoothly, replace it.

NOTE: The illustration shows the radiator fan.
