Home
>>
Acura
>>
1995
>>
TL L5-2451cc 2.5L SOHC G25A4 FI
>>
Repair and Diagnosis
>>
Engine, Cooling and Exhaust
>>
Cooling System
>>
Testing and Inspection
>>
Symptom Related Diagnostic Procedures
>>
System Does Not Operate at All
System Does Not Operate at All
Refer to troubleshooting charts,
Fig. 12,
for electrical cooling fan diagnosis.
